Portable Aluminum Base Plate Pedestrian Access Control RFID reader Automatic Tripod Tunrstile
Product description
The portable turnstile is the perfect waist high portable turnstile for a variety of applications ranging from athletic facilities, cafeterias,and schools, to amusement parks, stadiums, and office buildings.
This simple yet rugged model has been built to withstand the abuse of a mass transit system while maintaining an affordable budget price.
Wherever portable control of pedestrian traffic is necessary, these waist high turnstiles will perform flawlessly.
TECHNICIAL SPECIFICATIONS
| Product Name | Portable Turnstile Tripod Turnstile Type Pedestrian Traffic Portable Control Portable Turnstile |
| Material | 304 Stainless steel |
| Width of channel | <600mm |
| Length of rod | standard 500mm |
| Type | Power off rod fall down automatically. Manual lift up rod when power on |
| Control direction | Single direction or bi-direction(optional) |
| Alarm | Violence entry and following entry |
| Pass speed | 40 person/min |
| Voltage | AC110V~AC220V |
| Working temperature | -15℃ to 70℃ |
| Support reading methods | IC/ID/rRFID Cards, Fingerprint/Face recognition, Barcode, QR Code, ESD device |
| Extensible function | People counting, Voice Alarm, Image Capture |
| Working humidity | <95%RH. No condensation |
| Communication | TCPIP or RS485 |
MAIN FUNCTIONS AND FEATURES
1. Mechanical drive unit with solenoid locking mechanism eliminate the use of expensive electric motor and
reduce maintenance cost.
2. If arm rotated more than half, it will auto-rotate to the next idle position. If arm rotated less than half, it will
auto-rotate back to the current idle position.
3. Built in adjustable tensioner to control rotation force to minimize over rotation. Arm just need to be pushed
lightly to rotate therefore even elderly or children are able to use the turnstile.
4.Turnstile can be configured to be bi-directional or uni-directional. Housing is locked with special key to avoid
tampering.
5. Innovative and unique mounting surface ensures simple and convenient installation for system integrator.
6. Can be used with variety of access control devices: IC / ID card readers, bar-code scanner, fingerprints, etc.
(Access controller needed)
7. Automatic reset function. Should the user fail to pass within the prescribed time (default time is 5 seconds),
the system will cancel the authority of the current user automatically.
8. The mechanism is equipped with an automatic regulated hydraulic buffer device. There is no noise and impact
when running.
9. Auto-reposition function: After card read, passengers don't pass within regulated time period, turnstile will be
locked automatically
10. When power off, arm will be dropped automatically
