PRODUCT DESCRIPTION

Bollards are valuable tools for making roadways, public areas and private properties safer and more secure. Although these barriers may look like simple metal posts and are often easy to overlook, they are crucial when controlling or restricting vehicle access.

Bollards can help direct and control traffic flow so drivers know where and where not to go. They can also protect pedestrians from vehicles that would otherwise run onto a sidewalk or crash into a building. Bollards can also help homeowners limit vehicular access to their driveways.

Bollards come in several types, including solutions designed for permanent barriers and others for temporary use. Automatic retractable security bollards have the unique ability to raise or lower on command in a matter of seconds, making them a flexible protection solution for deployment in heavy-traffic areas. Automatic rising bollards facilitate more efficient traffic flow and increase security by making it easier to control vehicle access to a property or facility. Automatic bollards also provide greater convenience when compared to many other types of bollards.

PRODUCT DETAILS

1. System:electric-hydraulic system
2. Max passing pressure: 80T to 120T trucks
3. Voltage:AC220V 50Hz Integrated
4. Power(w):300W Integrated
5. Up time:4.5S
6. Down time:3S
7. Working temperature:-65℃~75℃
8. Storage Environment:-10℃~65℃(water-proof, damp-proof,dust-proof)
9. Material:304 stainless steel
10. Rising height:600mm standard, Max. can be 1000mm
11. Bollard Thickness: 6mm standard ( 8mm, 10mm, 12mm, 20mm are optional)
12. Diameter:219mm Standard ( 168mm, 273mm, 324mm are optional)
13. Structure :With load-bearing steel beam column, anti-collision steel beam column, 4 navigation rod
14. Integrated electrical mechanism : stroke 600mm, Cylinder outer diameter 60mm, Rod diameter:16mm.
15. 6k Mirror tube(optional)
16. LED light (optional)
17. Reflective sticker: 1 or 2 strips
18. Link-control interface
19. In case of a power outage, the bollards can be manually lowered down
20. IP rate: IP68
21. Net Weight:60±KG Integrated
22. In rising and falling,reversible operation is available
23. Device running noise≤60decibel
24. Waterproof integrated hydraulic device drive
25. The hydraulic cylinder is double sealed to ensure a waterproof rating
26. Hydraulic drive comes with hydraulic lock
27. PLC programming command control box (chip control box optional)
28. Solenoid valve voltage 24V
29. Remote control distance 50m(Based on the environment)
30. The control box displays text adjustable (Up, Down, Action, Time control is adjustable)
31. Text display with Chinese and English bilingual langague.
32. PLC built-in encryption system
33. Water immersion performance:48 hours without leakage and working well

TECHNICIAL SPECIFICATIONS

Automatic bollard features

High security and anti-collision ability

Pneumatic air pump in control cabinet could procide large power safely for a long time.

Electronic control, automatic rise/fall

High system independence

Automatic bollard Reflective band

Various color options for Glossee aveolate reflective band; only need weak light to be clearly visible at night.

Automatic bollard Materials Available

304 stainless steel, 316 stainless steel and carbon steel with electrophoresis spray paint.

Automatic bollard Flange

Anti-skid flange with unique some pattern design. Compatible with various road surface styles. Built-in PA orientation.

Automatic bollard​ Top cap

Its simple integration design is compatible with all kinds of architectural style. Excellent workmanship is amenable to any close attack.
