PRODUCT DESCRIPTION

This 2nd generation servo motor gate adopts integrated design and mold manufacturing with international leading technology,compact structure, high precision, high consistency and standardization, and use planetary reducer transmission, high efficiency, long life, no oil leakage, no blocking, low noise, the motor adopts 24V permanent magnet rare earth synchronous servo motor, small size, low power consumption, large torque, wide speed regulation, no heat, small penetration, precise limit, etc., using digital signal processor (DSP) As the control core, it can realize more complex algorithms, realize network and intelligence, (IPM) internal integrated drive circuit can detect faults and display fault codes to quickly solve fault problems. The three-bar linkage design of the machine core makes rapid rise and stable fall. Using solar charging applications, it is suitable for unmanned occasions such as railway crossings, fire passages, oil stations, mine tunnels, etc., without electricity, and fully realizes automatic operation control.

FUNCTIONS

1. Operation speed can be adjusted.

2. Slow up and slow down can be adjusted.

3. The limit angle can be adjusted.

4. Left and right direction can be quickly interchanged.

5. The barrier arm can be manually operated in case of power failure.

6. 418 frequency learning code anti-copy remote controller.

7.Infrared photocell sensor I/O signal input function.

8. Loop detector and radar I/O signal anti-collision signal input function.

9. Up, down and stop I/O signal input function.

10. Counting (fleet) function.

11.LED light I/O signal output function.

12.Traffic light I/O signal output function.

13.Up and down in place, normally open and normally closed signal output function.

14.RS485 communication output function.

15.Delay arm drop function.

16.Arm auto-reverse function.

17.Automatic lifting function when power is off (requires additional power storage module).

18.I/O port single-key cycle up and down function.

19. Loop detector normally open and normally closed function.

20.One car passes through each signal to prevent toll evasion function.

21.Anti-collision alarm function (requires additional alarm and sensor).

22. Fire linkage signal input function.

23.The I/O port closes the signal input function.

24.24V storage battery input function.

TECHNICAL SPECIFICATIONS
