    Advertising Airborne Boom Barrier Gate Remote Control DC Brushless Motor

    Ask Lasest Price
    Brand Name : SINOMATIC
    Model Number : SN-BG-AD01
    Certification : CE/ ISO
    Price : negotiable
    Payment Terms : T/T, Western Union, MoneyGram, D/A, L/C, D/P
    Supply Ability : 1,000pcs per month
    Delivery Time : 5-10 working days after payment received
    • Product Details
    • Company Profile

    Advertising Airborne Boom Barrier Gate Remote Control DC Brushless Motor

    CE Remote Control Traffic Parking DC Brushless Motor Advertising Boom Barrier Gate


    PRODUCT SPECIFICATIONS


    Working temperature
    -30℃~+65℃
    Power supply
    24VDC
    3Open/close speed
    3 sec to 8sec adjustable
    Rated power
    200W
    Driving method
    DC brushless motor
    Humidity
    ≤90%
    Remote distance
    ≤100m( open place, sunny weather)
    Protection grade
    IP54
    Motor no-load speed
    2500r/min
    Max boom length
    4.5m
    CE, ISO
    YES

    Our Advantage

    1. 3 second to 8 second open/close time adjustable;

    2. Advertising DC brushless motor & 5 million MCBF;

    ​3. 5 tension spring balance makes is heavy duty and more durable;

    ​4.Led lights with time swtich ,set a time for light on as you require;
    5. Simplified design, easy installation and maintenance reduces your labor cost;

    8.1 year standard warranty, excellent after-sales service;

    9. 24h*7d at your service to give you best support;

    Functions and features

    1 The running speed can be adjusted from 3sec to 8 sec.

    2 Open the barrier by the motor wheel when the power is off. Automatically reset when power on.

    3. Curved crank arm three-link movement structure, operation stable

    4 Wireless remote control open and close.

    5 Arm auto-reverse( force adjustable)

    6 Infrared photocell is available

    7 Loop detector is available

    8 Connect parking management system open, close signal.(request open and close signal)

    9 Traffic light port(2A12V/220VAC, less than 40W traffic light can be used)

    10 Offering limit signal for car parking management system( output COM/NO/NC)

    11 RS485 or CAN internet communication interface( no need to add module)

    12 Counting interface

    13 24 backup battery interface(can be connected with solar power)Offering dry contact signal for car parking system(COM,NC,NO)

    14 Auto-delay when closing(adjustable)

    15 RS485 or CAN network communication interface(no need to install module)

    16 Counting interface

    17 24V backup battery interface(Can be charged by using solar energy)


    PACKAGE


    Packed in bubble wrap firstly, and then reinforced with carton for outer packing.


    Packing list
    NameSpecificationsQuantityRemarks
    Machine coreGood in working1Main part
    Barrier armStraight, folding or fence arm1Optional
    Boom press board1Fixing the boom
    Self-tapoing screwST4*16Fixing the boom
    Self-tapoing screwst3*104Fixing the boom
    Supporting pole1Fupporting the boom
    Expanion boltM16*1504Fixing the case
    Hexagonal Inner ScrewM8*354fixing the case
    Clutch key1clutch device
    Case Key2for case and cover locking
    Balance springAccording to length of barrier arm1for sapre usage
    Remote emitterless than 30m is available1For remote control
    Remote conrol handlesless than 30m is available2For remote control
    Instructionin English1For reference
    RS485 interface1Optional
    Disc1Optional
    Communication Mould1Optional
    Cover head13 years without fading
    Expanion nutM84Fixing the supporting pole
