    AC220V Automatic Door Opener 50 Meter Remote Control Wireless Automatic Gate Openers

    Ask Lasest Price
    Brand Name : SINOMATIC
    Model Number : SN-KMP202
    Certification : CE/ ISO
    Price : negotiable
    Payment Terms : T/T, Western Union, MoneyGram
    Supply Ability : 2,000 pcs per month
    Delivery Time : 5-10 working days after payment received
    • Product Details
    • Company Profile

    AC220V Automatic Door Opener 50 Meter Remote Control Wireless Automatic Gate Openers

    Electric Wireless 50 meter Remote Control Distance Max Loading 1800kg Automatic Door Opener


    Product description


    This is a conventional sliding gate operator,with brand-new design,brand-new clutch structurefashionable exterior design and brand-new control technique, making the motor more humanistic.
    Furthermore, the integrated electromechanical design and the streamlined appearance also make our product look more fashionable and elegant.



    Motor data


    ModelMP201KMP202
    Voltage220V±10%110V±10%220V±10%110V±10%
    Frequency50HZ60HZ50HZ60HZ
    Current2A4.5A2.7A5.8A
    Motor voltageAC220V / 110V
    Capacitor18μf60μf20μf60μf+14μf
    Output Power250W350W
    Absorbed power440W495W594W638W
    Torque22.5nm35nm
    Mode numberM=4
    Motor speed1350rpm1620rpm1350rpm1620rpm
    Reduction ratio23:1
    Gear speed58.5rpm70.2rpm58.5rpm70.2rpm
    Travel speed11m/min13.2m/min11m/min13.2m/min
    Working temperature-40°C∼+55°C
    Overload protection temperature130°C
    Motor making techniqueDie casting aluminum alloy
    Manual ReleaseYes
    Product weight(approx)9.13kg9.18kg10.19kg10.25kg
    Max.weight of gate1000kg1800kg

    Electronic Date

    ModelKMP201KMP202
    Soft startYES

    Stop on obstacle

    (sensitivity adjustable)

    YES

    Auto warming-up

    (at freezing temperature)

    YES
    Remote control418MHZ(50m,approx)
    Wire controlAvailable
    Auto closingYES
    Vehicle loop detector socketYES
    Photocell socketYES
    Alarm light socketYES

    Function and features


    1) Integrated mechanical and eletrical,all functions on one controller


    2) Radio controller or linesto control open,close and stop functions


    3) Magenetic limit switch,the door stops when it moves to the limit


    4) Accurate limit braking


    5) Electronic soft-start


    6) Dialing switches to adjust the motor rotation in both directions


    7) Open and close limits have a self-locking function


    8) Intelligent operation-if an obstacle is detected when the door is closing,it will reverse to open,then after 10 seconds it attempts to close automatically unless you press the stop key-stroke.


    9) Movement indication-the indicator lights up when the door is moving.


    10) Optional line control or remote control


    Product description

    • Power supply range: AC220V/110V±10% 50/60Hz
    • Net weight: 8.5kg
    • Max loading weight: 1800kg
    • Working temperature of motor: -25 to +55 Celsius degree
    • Working humidity: ≤85%
    • Rated power: 200w
    • Output gear module: M=4
    • Output gear number: Z=16
    • Open(close) speed: v=12m/min
    • Maximum pull: 1100N
    • Package one set in one carton
