    Full Height Acrylic Automatic Sliding Gate Turnstile 24V BLDC Motor IP54

    Ask Lasest Price
    Brand Name : SINOMATIC
    Model Number : SN-SLB02
    Certification : CE/ ISO
    Price : negotiable
    Payment Terms : T/T or western Union
    Supply Ability : 1,000 pcs per month
    Delivery Time : 5-10 working days after payment received
    • Product Details
    • Company Profile

    Full Height Acrylic Automatic Sliding Gate Turnstile 24V BLDC Motor IP54

    Shenzhen Manufacturer Full Height Acrylic Automatic Sliding Gate Turnstile


    PRODUCT DESCRIPTION


    * Sliding turnstile gates are in line with the modern trends of all the turnstile series. Thus, you can find them quite popular in office buildings as a pedestrian flow control solution.


    * As the name suggests, the doors open and close horizontally in a sliding way. Doors are made of acrylic, which can be replaced by the tempered glass as an optional choice.


    * The cabinet is made of 304 stainless steel which is strong and anti-corrosion for long-term serving. Customers can also use 316 stainless steel as an optional choice but the price will be a little higher.


    * Arrow shape led indicates the status of passage. When the lights are in green color, it means the lane is ready, and red means you can not pass this way.


    * Pairs of sensors are equipped for high-level security, additional pairs are optional for top safety.


    * These sliding turnstile gates are usually integrated with face recognition, fingerprint recognition, and other biometric identifications, also other traditional modules are supported, such as IC card, ID card, RFID card, bar code, etc.


    * Two motors can be fixed in one cabinet for customers who want to form multiple-lane pedestrian solutions. Brush motor is standard and brushless or servo motor is optional.


    TECHNICIAL SPECIFICATIONS


    Material
    304 Stainless Steel
    Dimensions
    1200*330*980 mm
    Barrier length
    250mm
    Dry Contact
    12V
    LED indicating light
    One
    Card-reading window
    Two
    Rated power
    100W
    Operating temperature
    -25℃ ~ +60℃, RH ≤90%
    Related humidity
    ≥90%RH
    Comunication Interface
    RS485,distance ≤1200m
    Power supply
    AC100V~240V, DC24V
    Transit speed
    30 persons per minute

    PRODUCT HIGHLIGHTS


    The body is made from brushed stainless steel which creates a seamless and elegant access point to

    blend into most indoor environment.


    It can be integrated with any kind of access controller system (e.g.: RFID device, Push button, Fingerprint

    and Biometric device).


    In case of emergency, the Optical Turnstile arm will open automatically to allow free passage.

    Optical Turnstiles are suit for elegant and luxury entrance solutions.


    DETAIL FUNCTION AND FEATURES


    1. Fault detection and alarm functions, easy to use and maintenance


    2. The running status can be programmed and controlled with the built-in keyboard on the main board


    3. Mechanical anti-pinch function. If the gate meets resistance in the reset process, motors will stop working

    automatically within the prescribed time and reset again after the default delay (till fully reset)


    4. Anti-breakthrough function. The gate is locked automatically until opening signal received


    5. Support infrared photocell for anti-pinch and reset function


    6. Automatic reset function. Should the user fail to pass within the prescribed time (default time is 5 seconds),

    the system will cancel the authority of the current user automatically


    7. Gate can be set as normally open or normally closed


    8. Can be used with variety of card readers: IC / ID card readers, bar codes, fingerprints, etc. (Access controller

    needed)


    9. Direction can be set as single-direction or bi-direction


    10. LED direction indicator


    11. Gate auto opens when power off and auto close when power on


    12. Alarm function, in case of illegal intrusion and reverse intrusion, etc.
