    Integrated Channel Swing Gate Anti Collision TCP IP Handicapped 200W

    Ask Lasest Price
    Brand Name : SINOMATIC
    Model Number : SN-ISB10
    Certification : CE/ ISO
    Price : negotiable
    Payment Terms : T/T or western Union
    Supply Ability : 500 pcs per month
    Delivery Time : 5-10 working days after payment received
    • Product Details
    • Company Profile

    Integrated Channel Swing Gate Anti Collision TCP IP Handicapped 200W

    Anti Collision Airport Entrance boarding TCP/IP Handicapped 900mm Passing Integrated Channel Swing Gate


    DESCRITPION


    1. Integrated swing gate is designed to control pedestrians entering or exiting restricted areas, usually

    used of high pedestrian traffic flow in both directions.
    2. The body is made from brushed stainless steel which creates a seamless and elegant access point

    to blend into most indoor environment.
    3. It can be integrated with any kind of access controller system (e.g.: RFID device, Push button,

    Fingerprint and Biometric device).
    4. In case of emergency, the Optical Turnstile arm will open automatically to allow free passage.
    5. Optical Turnstiles are suit for elegant and luxury entrance solutions.



    DescriptionParameters
    Lane Width900-910mm
    IPIP54
    Pass Speed30 persons/min
    Power supplyAC220V/110V,50/60Hz
    Drive ModeMotor drive
    Max Power Consumption200W
    Opening time0.5S
    Humidity≤90% coagulation free
    Noise≤50dB
    Service Life5,000,000 cycles
    Outside packing145x110x36cm
    Working Environment-20°C~+60°C
    Gross Weight85KGS

    PRODUCT DIMENSION


    FEATURES AND FUNCTIONS


    1. DC brushless motor is maintenance-free and new digital positioning.
    2. Mechanical anti-pinch; optional in online mode or offline mode.
    3. Real-time fault self-test and alarm prompts to ensure safe operation of the system, easy to maintain and use.
    4. It has the light indication and the gate induction automatic lock function to guide pedestrians

    to enter and exit the passage and prevent forced passage.
    5. Emergency or special situation processing mode; with standard input and output interfaces,

    it is convenient for the system to integrate with other devices, and can realize remote control and management.
    6. Super combination ability, different styles, series channel products can be combined without affecting

    system performance.
    7. Powerful system expansion capability, new products can be added at any time.
    8. Remote control management: The state of the gate is operated remotely to meet the special needs of users and

    fire safety requirements.
    9. Powerful self-checking function: The device is in fault monitoring state at any time. The error reporting function

    is friendly. The human-computer interaction is realized conveniently and quickly to realize maintenance;
    10. Good anti-collision function (when the gate is in the state of opening and closing, if there is an object hitting the gate,

    it will stop moving and reverses back.
    11. The service life is as high as 5 million times.


    PRODUCT DIMENSION

    PRODUCT ADVANTAGES


    PRODUCT MECHANISM
