Product Features

1 The running speed can be adjusted from 3sec to 10sec.

2 Open the barrier by motor wheel when power off.Automatically reset when power on.

3 Curved crank arm three-link movement structure,operation stable

4 Wireless remote control open and close.

5 Arm auto reverse( force adjustable)

6 Infrared photocell is available

7 Loop detector is available

8 Connect parking management system open, close signal.(request open and close signal)

9 Traffic light port(2A12V/220VAC, less than 40W traffic light can be used)

10 Offering limit signal for car parking management system( output COM/NO/NC)

11 Delay closing arm function

12 RS485 or CAN internet communication interface( no need to add module)

13 Counting interface

14 24V backup battery interface(can be connected with solar power)

Arm length speed comparison table

(the parameter is based on arm of our company)

Technical parameters

1 Working temperature(motor): -35℃~+85℃

2 Rated voltage:DC24V

3 Running speed:3s-10s

4 Rated current:9.5A

5 Rated power:250W

6 No-load speed:2500rpm

7 Rated speed:1800rpm

8 Output Power:120N.m

9 Relative humidity:≤90%

10 Remote control distance:≤100M(in the open place)

11 IP Degree:IP44

12 Max length of arm:4.5M

Product advantage

1. 3second to 8 second open/close time adjustable;

2. Advertising DC brushless motor & 5 million MCBF;

​3. 5tension spring balance makes is heavy duty and more durable;

​4.Led lights with time swtich ,set a time for light on as you require;

5. Simplified design, easy installation and maintenance reduces your labor cost;

6. Fast finishing time for you to become more competitive at your local market :3-5 days for small order;

7. OEM Brand, Logo, Label available;

8.1year standard warranty, excellent after-sales service;

9. 24h*7d at your service to give you best support;

PRODUCT SPECIFICATIONS

PACKAGE

Packed in bubble wrap firstly, and then reinforced with carton for outer packing.
