    Brushless Motor RGB LED Indicator Flap Barrier Gate SS304 Cabinet

    Ask Lasest Price
    Brand Name : SINOMATIC
    Model Number : SN-FB02
    Certification : CE/ ISO
    Price : negotiable
    Payment Terms : T/T or western Union
    Supply Ability : 3,000pcs per month
    Delivery Time : 5-10 working days after payment received
    • Product Details
    • Company Profile

    Brushless Motor RGB LED Indicator Flap Barrier Gate SS304 Cabinet

    SS304 Cabinet Remote Control Brushless Motor Optical Detection RGB LED Direction Indicator Flap Gate Turnstile


    PRODUCT DESCRIPTION


    Sinomatic flap barrier can be compatible with IC card , ID card ,barcode card , fingerprint reading card recognition

    device used for staff, provide civilized , orderly access methods; effectively manage the access of staff .


    OPTIONAL FUNCTIONS

    • Auto bidirectional counter
    • Voice prompt,
    • Arm material and color
    • Housing shape for optional:sharp-angle,round angle,octagonal -angle,arc bevel-surface etc.

    UNIQUE FEATURES


    ♦ Adopt Brush-less motor,it has longer lifespan.
    ♦ Adopt control technology,which has stronger function and better expand-ability.
    ♦ Flow rate more fast,and switching speed up to less than or equal to 0.5s
    ♦ Low noise,sound can be achieved less than or equal to 20 decibels.
    ♦ Running more smooth,that is no shaking,no shake,no echo.


    PRODUCT APPLICATION RANGE


    Airport terminal,Metro,bus station and massTransportation;
    Governmental facilities &State Institutions;
    Outdoor/Indoor Public Areas,,Fitness and Sport Halls;
    Industrial Plants;Bank,Hosptial lobby,construction sites;
    Universities and other Education Institutions,childcare centers;
    Military and Defence Facilities;
    Business Centers and Plazas;
    Tourism and Historical Facilities;
    Ticket Authentication and Process Integration Applications.


    TECHNICIAL SPECIFICATIONS


    Model NumberSN-FB02
    Passage width≤600mm
    Throughput rate30p/m
    Power supplyAC100-240V,DC24V
    Motor voltageDC24V
    Max power consumption35W
    Frequency50Hz,60Hz
    prectection levelIP44
    Working temperature-20℃~60 ℃
    Dimension excluding bars1200X300X1000mm
    Net weight50kg
    Optional devices1.Fingerprint reader 2.Face recognition 3.Card collector
    4.Card reader 5.2D scanner 6.Palmprint reader

    MAIN FUNCTION AND FEATURES


    1. Equipped with standard card read window, can be widely integrated with multi access control system,

    biometric authentication system.


    2. The running status can be programmed and controlled with the built-in keyboard on the main board.


    3. Mechanical antipinch function. If the gate meets resistance in the reset process,motors will stop working automatically

    within the prescribed time and reset again after the default delay (till fully reset)


    4. Anti-breakthrough function. The gate is locked automatically until opening signal received.


    5. Synchronization functions (for dual gate equipment).


    6. Automatic reset function. Should the user fail to pass within the prescribed time, the system will cancel the authority

    of the current user automatically.


    7. Gate can be set as normally open or normally closed.


    8. Can be used with variety of card readers: IC / ID card readers, bar codes, fingerprints, etc.


    9. Direction can be set as single-direction or bi-direction.


    10. LED direction indicator.


    11. Gate auto opens when power off and auto close when power on, complying with fire safety requirements.


    12. Alarm function, in case of illegal intrusion and reverse intrusion, etc.


    13. Counter function (optional).


    14. Support infrared photocell for anti-pinch and reset function


    OPTIONAL DESIGN
