PRODUCT DESCRIPTION

The product consists of four parts: Housing, transmission mechanism, control unit, and boom. It’s no need to distinguishes between left and right directions. It’s is used in application scenarios for vehicle access management in residential areas, commercial properties, enterprises and institutions. This barrier gate is a heavy-duty type for with fence boom.

TECHNICAL SPECIFICATIONS

*Housing dimension: 650×655x1650mm

*Motor type : BLDC Motor

*Motor Power : 200W

*Total length : < 6m (include housing)

*Boom useful length: ≤ 5.35m

*Operation Speed : 4s-9s

*Operating voltage : DC24V

*Operating Temperature : -30℃-60℃

*Insulation level: F

*Protection grade: IP54

FUNCTION AND FEATURES

1. Safety: Powered by a 24V DC power supply to ensure personal safety.

2. Adjustable speed: The lifting and lowering speed of the boom can be independently adjusted.

3. Stable operation: The movement adopts a DC brushless motor, which has a large output torque and small size. The speed can be adjusted arbitrarily through the controller. When the falling or lifting boom is in place, deceleration buffering is achieved, making the boom smoothly in place.

4. Quiet: The working noise is below 50db;

5. Material: The main body of the movement is made of aluminum alloy material, manufactured by die-casting technology, with reliable mechanical strength, beautiful appearance, precise size, and good heat dissipation.

6. Multiple protections: motor overcurrent, overload, short circuit protection, motor fault protection, power reverse connection protection;

7. Supports external remote control input;

8. Supports open position, close position, and status dry contact output, and can be controlled by external light strips or indicator lights to output the current status;

9. Supports RS232/RS485 serial communication

10. Support opening counting function and unmanned automatic closing function

11. Support high sensitivity anti smashing and rebound protection function

KEY FEATURES

PRODUCT PARAMETERS

CASE REFERENCE

Founded in 2002, SINOMATIC is a national high-tech enterprise specialized in R&D，production, and sales of intelligent access control products. It has nearly 200 patented technologies. Its main products including Access control turnstile, parking barrier gate/parking lock, Automatic gate opener, Anti-terrorism roadblock, etc., are suitable for the entry and exit management of vehicles and personnel such as government building, high-speed toll gate, commercial plaza, residential areas, stations, customs checkpoints, etc.

SINOMATIC has strong innovation and R&D capabilities, ultra-high technology, and craftsmanship, leading the industry into the era of intelligent variable speed interconnection.

As an innovative enterprise, SINOMATIC has always been committed to building an efficient and innovative R&D team to continuously promote technological and product innovation, improve the core competitiveness and market share of the enterprise.

At the same time, SINOMATIC attaches great importance to the construction of the talent team and focuses on introducing and cultivating high-quality R&D personnel in the field of research and development.

Technological innovation, product quality, and manufacturing capabilities are the driving force of SINOMATIC's continuous development. Brand, channels, and after-sales service are the pillars of SINOMATIC's long-term development. SINOMATIC products are sold all over the world. It has set up agency service outlets in more than 150 countries and regions including United States, Canada, UK, France, Germany, Russia, India, Singapore, Malaysia, Indonesia, Thailand, Turkey, Israel, UAE, Saudi Arabia, South Africa Nigeria, Kenya, etc.

With superior product quality and a high-quality after-sales service system, "SINOMATIC" has become a world-renowned brand of Access control products. SINOMATIC always keeps forging ahead, makes every product with hearts, and adheres to build trustworthy SINOMATIC quality and Chinese national brand in the world.
